Cooking Screw Oil Expelling Machine/Small Oil Press For Sale

FOB Reference Price:Get Latest Price
$1,500.00 - $3,500.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
6YL-160
Power(W):
5.5kw
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Warranty:
1 Year
Production Capacity:
98%-100%
Usage:
pressing oil
Applicable Industries:
Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Food Shop, Construction works
Condition:
New
Type:
Cold & Hot Pressing Machine
Automatic Grade:
Automatic
Place of Origin:
Henan, China
Brand Name:
Qi'E
Voltage:
220V/380V
Dimension(L*W*H):
1700*1100*1600mm
Weight:
1200kg
Certification:
ISO9001
After-sales Service Provided:
Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Online support
Screw speed:
28-40 r/min
Gear ratio:
15/38x15/52=1:8.78
Dimension:
2500x1600x2500mm
Productivity:
450-600kg/h
Vacuum pump:
Y100L1-4-2.2KW
Heater:
4Kw
Power:
Y200L-6-18.5KW
Production Condition:
Staff 2-3, plant 60-80
Technology:
First-class
Quality:
Excellent
Supply Ability
Supply Ability:
50 Set/Sets per Month small oil press for sale
Packaging & Delivery
Packaging Details
All the packages are the wooden cases of small oil press for sale.
Port
Qingdao or any nearest port
Product Description

 Cooking Screw Oil Expelling Machine/Small Oil Press For Sale


Equipment Introduction of small oil press for sale:

The oil press machine is a new research improvement product. It can use to press Copra, rapeseed, peanuts, soybean, sesame,sunflower seeds and other plant oil materials. This kind of machine adopts micro-electrical control, filter system, multi-stage press and cold and hot press. The product oils the clean oil after filtering, it can directly to use. The machine is the most ideal equipment for individual processing.
6YL series spiral oil press is mainly composed of 7 major parts of screw axis, press cage, feed mechanism, cake yielding mechanism. transmission system, electric control part and vacuum filter part. All the parts are assembled on the frame and screwed as a whole.

Operation of small oil press for sale:

1.When oil press is on work, material enters the extruding chamber from the hopper and then moves forwards by the rotating pressing screw and is pressed.
2.Under high temperature condition in the chamber, there is quite strong friction among press screw, chamber and the oil materials.
3.On the other hand, root diameter of the pressing screw carries larger from one end to the other.
4.Hence when rotating, the thread not only pushes particles moving forwards but also turns them outwards as well.
5.Meanwhile, particles adjacent the screw will rotate along with screw's rotating, causing every particle inside the chamber to possess different speed.
6.Therefore, relative movement among particles creates neat which is necessary during manufacturing because of helping protein change property, damage colloid, increase plasticity, decrease oil's elasticity, resulting in high oil.

Advantage:

High oil yield - The oil yield can be improve 2 to 3 percentage points than older equipment.
Energy saving - With same output reduces electricity power by 40%.
Labor saving - With same output can save 60% of labor, and 1 to 2 people can organize production.
Pure oil - Vacuum filtration residue to ensure the purity of oil, in line with health and quarantine standards.
Small footprint - 10-20 square meters to meet the needs.
Precision manufacturing - High alloy carbon steel, high frequency quenching and heat treatment, which improves the service life of the oil press.

Detailed Images
Model
6YL-80
6YL-100
6YL-120
6YL-130
6YL-160
Speed of press screw(r/min)
30-40
30-40
30-40
28-40
28-40
Boundary dimension(mm)
1650*1150*1750
900*1300*1850
2200*1650*2100
2300*1600*2100
2400*1700*2100
Capacity(kg/h)
80-150
150-250
200-300
300-400
400-600
Heater(kw)
2
3
3.3
3.8
4
Residual oil rate
6-7%
6-7%
6-7%
6-7%
6-7%
Weight(kg)
680
870
1280
1420
1600
Power(KW)
5.5
7.5
11
15
380V, 18.5 KW
Vacuum pump
Y90S-4-0.55KW
Y90S-4-1.1KW
Y100L1-4-1.5KW
Y100L1-4-2.2KW
Y100L1-4-2.2KW
Product condition
1 Staff ,plant 20-30㎡
1-2 Staff ,plant 30-50㎡
2 Staff ,
plant 40-50㎡

2-3 Staff ,plant 40-60㎡
2-3 Staff ,plant 60-80㎡

Operating principle:

1.Material enters the extruding chamber from the hopper.
2.There is quite strong friction among press screw, chamber and the oil materials.
3.Root diameter of the pressing screw carries larger from one end to the other.
4.Last,helping protein change property, damage colloid, increase plasticity, decrease oil's elasticity, resulting in high oil.


Part of groundnut cooking oil making machine


(1) Electric control box:Fully automatic control of the machine saves manpower and efficiency.
(2) Discharge hopper:Material enters from here.
(3) Screw axis:Press the material to extract the oil from the material.
(4) Filter:Filter out impurities in the oil to improve the quality of the oil.
(5) Frame:Support the machine to ensure that the machine works properly.

Packing & Delivery

Any special requirement of shipping, please talk with us, we will help you to solve the problems.
if the amount of goods to be deliverd is relatitively small ,the goods will be packaged in the form of export wooden boxes .if the goods are shipped in the large quantities,the goods will be directly loaded into the containers and cut and reinforced to prevent the goods from colliding.

Our sevirces

Pre-sale services:

1) Selecting equipment type;
2) Designing and fabricating the products in accordance with the special requirements of the clients;

Services provided during the sale:


1) Checking products acceptance ahead of delivery;
2) Introducing the service system to our clients;

After-sale services:


1) Installing and testing the equipment;
2) Training the first-line operators on site;

Certifications
FAQ

Q:Are you a manufacturer or a foreign trade company?
A:We are an industry and trade integrated company.

Q:What if I don't operate this product?
A:Our machine operation video and manual are for your reference. If necessary, we will send engineers to train for you personally.

Q:Can you provide more information about production and quote the best price?
A:Of course, but first we have to confirm your needs. According to your needs, we will choose the right product for your reference. When we determine one or several products, we will quote you the best price.

Q:How to place an order?
A:First send us the enquiry below, including the device name, daily production, work hours, main processing materials, etc., then our sales manager will send you the information for your reference.

Q:How long does it take to receive my product?
A:It is not yet possible to determine the time because the shipping distance and production cycle are uncertain.our business manager will recommend the appropriate transportation route for you to ensure safe and fast delivery of the goods.

Q:How is the quality of your products guaranteed?
A:After the completion of production, our quality inspection can not test the product. If you need it, we can provide third-party testing service to ensure the stable production of the equipment.

Company

Zhengzhou Qi'E Grain&Oil Machine Co Ltd is located in Zhengzhou City, Henan Province, China, and has strong strength in grease machines.

1. More than 30 years of experience
The factory is located in Henan Province, China. We are very welcome to visit our factory. If you need it, we will arrange a pick-up.
2.Top production team
The transportation and packaging will be packaged in international standards. If you have special packaging requirements, we will give you the most suitable solution.
3.High quality products
Our sales manager will send you a production progress picture or video every day, so that you can know the production progress of the product in real time, and we accept L/C payment.
